The following applications can be implemented in any combination:
Control of DALI devices on group level
with up to 4 groups (fix G0-G3 and broadcast)
Control of DALI devices on short address level
with up to 4 DALI short addresses (fix A0-A3)
Controlling an RGBW luminaire in DALI
DALI Device Typ 8
Controlling Casambi devices and scenes
in a Casambi network
Gateway: From DALI to Casambi
(certain Casambi devices are emulated as DALI control gear)
Following applications are possible
Applications
Adress Controller
Control of DALI devices on short address level
bis zu 4 DALI-Kurzadressen (fest A0-A3).
Group Controller
Control of DALI devices on group level
with up to 4 groups (fix G0-G3 and broadcast)
RGB+W Controller
Controlling an RGBW luminaire in DALI
Gateway
Gateway: From DALI to Casambi
(certain Casambi devices
are emulated as DALI control gear)
Product data CI4 / DALI:
4-fold push-button-interface
4 volt free inputs
Casambi Repeater
Powered from DALI
Dimensions: 44 x 29 x 16,5 mm
Part. No. 10.800
